Result
After OS compilation and subsequent download, the setting is applied in the process control
and saved in the "@ExportPath" tag.
Files of the (filtered) total export are additionally stored at the specified storage location.
5.11.2.3 Navigation information in the screen
Introduction
In the "Navigation information in the screen" area of the "Other settings" dialog, you specify
whether and at which location the path will be displayed within the plant hierarchy in the
diagnostic screen in the process control.
The path can be displayed at the following positions in the diagnostic screen:
● Top left
● Top center
● Top right
● Bottom left
● Bottom center
● Bottom right
The overview screen of the diagnostic screens is not affected by these settings.
Note
This function is available if you configured the Maintenance Station in the MS Standard version.
Requirement
The Maintenance Station has been created.
Procedure
1. Open the plant view in the SIMATIC Manager.
2. Select the object in the tree view:
– If you are using a multiproject, select the object "[name of the project] MP".
– If you are using a single project, select the object "[name of the project]".
3. Select the menu command Options > Plant Hierarchy > Advanced Diagnostics Settings....
The "Advanced Diagnostics Settings" dialog box opens.
4. Select the "Other settings" tab.
5. Select the "Display" check box.
6. Select the position for the display of the path in the diagnostics screen.
Configuring the maintenance stations
5.11 Advanced diagnostics settings
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 67
