5.13.4 Assigning parameters for the AssetM block
Overview
After the AssetM block has been placed in the CFC, interconnect the parameters that are to
be used.
In order to display information in the faceplate from SIMATIC PDM for the monitored
component during process control, a SIMATIC PDM object must be created for each AssetM
block in the process device plant view.
This SIMATIC PDM object saves the rating plate (identification data) and the diagnostic texts.
The "AssetMon" device is assigned to the SIMATIC PDM object.
The PLT ID is a connection parameter between a SIMATIC PDM object (parameter data EDD)
and the faceplates in the Maintenance Station.
The PLT-ID is linked to the SIMATIC PDM object.
Procedure
The PDM object is created in SIMATIC Manager as follows:
1. Select View > Process Device Plant View in SIMATIC Manager.
2. Select a project in SIMATIC PDM in which you want to insert the SIMATIC PDM object.
3. Select File > New object.
4. Select the inserted object with the right mouse button.
5. Select Device selection (Reassign)... in the shortcut menu.
6. In the tree structure, select Devices > DATA_OBJECTS > CFC > Siemens AG >
AssetMon.
7. Click OK.
8. Select the object with the right mouse button.
9. Select Open object in the shortcut menu.
10.Enter all required data in the parameter assignment mask.
11.Select File > Save and close the parameter assignment mask.
12.Enter the generated PLT ID for the associated "PLT ID" block parameter.
Note
The PLT ID cannot be changed or deleted.
Additional information
You can find additional information on the AssetM block in the manual
Process Control System
PCS 7; Advanced Process Library
.
Configuring the maintenance stations
5.13 Configuring the user diagnostics
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 73
