Display
● Status of the component
The following table shows the icon representation of the statuses:
Icon identification Meaning
No icon No state
No detail information pending or available
Pending fault
There was a fault for a time
Operator control
Icon Explanation Permission
You open the legend by clicking the icon.
The legend shows the icons designating the possible
statuses and their meaning.
No access protection
With Profile V1.4 and higher, the stored statuses are
reset when you click the icon.
"Process controlling" for the di‐
agnostics area
6.11.3.6 "Connection display" view for client components
Available
The view is displayed for all OS clients, MS clients and OS/MS clients from the area of the PC
objects.
Note
This view is available for the maintenance station in the MS Standard version.
Overview
This view shows all servers, the server data of which are downloaded to the client.
Servers are OS servers, MS servers and OS/MS servers.
The following figure shows an example of the view:
Operator control and monitoring
6.11 Faceplate
Maintenance Station
154 Function Manual, 03/2016, A5E36187641-AA
