Operator control
Icon/
Name
Explanation Operator permis‐
sion
"Maintenance job"
area
● Alarm
● Prompt
● Request
A maintenance job is requested by clicking an option button. "Process control‐
ling" for the diag‐
nostics area
"Requested action"
area
You select an action from the drop-down box.
An action, for example, can be "Disassembly".
You can find information on configuring an action in the
section "Configuring maintenance actions (Page 58)".
"Time requested"
area
The time of the request of the maintenance job is specified
in the input box. The time is entered in the following format:
YYYY.MM.DD - hh:mm.
"Status Service" area
● In service
● Release request
● Planned
servicing
● Completed
● Cancel
By selecting an option button, the maintenance job is given
a processing state.
"Passivate" check
box
Available for PC and IPC objects
The PC object is passivated by clicking on the check box.
You can find information on passivation in the section "Pas‐
sivating PC objects (Page 194)".
"Memo" area The maintenance engineer can enter a note for the service
job in the memo field or change a saved note.
The text is applied to the individual export file.
In order for the note text to be saved as a comment for the
operator message and permanently displayed in the memo
field, one of the following operator actions is required in
addition to entering the note text:
● Change the type of maintenance job in the maintenance
job area
● Switch between the service types 'In Service' and
'Planned servicing' (bilateral) in the Status Service area
The note text is deleted when you complete or cancel the
maintenance job.
"Targets" area
● Check boxes
By selecting this check box, the single export file is
stored in the selected target.
● Drop-down box
Operator control and monitoring
6.11 Faceplate
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 149
