Siemens SIMATIC PCS7 Function Manual

Operator control
Icon Explanation Permission
Free area Text box for the note "Process controlling" for the di‐
agnostics area
The note is enabled or disabled by selecting the check
box.
● Enabling
The note is enabled when the check box is
selected.
The next time the faceplate is opened or there is a
process picture change, you can see in the status
bar of the block icon and the faceplate that there
is a new message for you.
● Disabling
The display in the status bar of the faceplate and
in the block icon is hidden.
The message is not deleted automatically.
Note
Keep in mind that a complete compilation of the MS (that is the MS for single-station systems
and the MS server for multiple-station systems) and subsequent downloading of the MS server
deletes the contents of the note view.
Operator control and monitoring
6.11 Faceplate
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 151
