Siemens SIMATIC PCS7 Function Manual

Diagnostic structure – MS Standard version
The table shows an example of the diagnostic structure.
Areas and levels
1 2 3 4 5 6 7 8
Diagnostics AS/system AS objects AS detail
view
-
DP master
system
DP nodes -
PROFINET
IO system
PN nodes -
Field devices AS objects
without their
own group
display
DP master
system
DP nodes Modules HART field
devices
-
PA field devi‐
ces
-
PROFINET
IO system
PN nodes Modules HART field
devices
-
PA field devi‐
ces
-
DP nodes
Network ob‐
jects
-
PC stations
User objects Depending on the configuration in the plant hierarchy
Diagnostic structure – SIMATIC MS PDM version
The table shows an example of the diagnostic structure.
Areas and levels
1 2 3 4 5 6 7 8
Diagnos‐
tics
Field devi‐
ces
Depending on the configuration in SIMATIC PDM
Network ob‐
jects
-
PC stations
Configuring the maintenance stations
5.10 Creation of the diagnostics structure
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 53
