Configuring/parameterizing
6
6.1 Configuration overview
In order that the machine or plant can perform the desired tasks, you must carry out the
following steps with SIMOTION SCOUT:
● Create a project:
The project is the generic term under which you store all of the relevant files.
● Configure hardware:
Provide the SIMOTION system with information about the hardware.
● Configure technology objects (TO):
Provide the SIMOTION system with information about the technologies used.
SIMOTION SCOUT provides wizards for comprehensive assistance.
● Create and test open-loop and closed-loop control programs.
● Commission and optimize drives and axes.
● Test the system and utilize the diagnostic options.
SIMOTION SCOUT provides the workbench to enable you to perform these steps easily and
efficiently.
6.2 SIMOTION SCOUT - basic settings
In SIMOTION SCOUT, you have the possibility of predefining various basic settings via the
Options > Settings menu. Detailed information on the individual tabs and settings is provided
in the SIMOTION SCOUT online help.
1. Open SIMOTION SCOUT.
2. Click the Options > Settings... menu.
The Settings window opens.
3. Click the desired tab.
4. Enter the settings.
5. Click OK.
Note
Select Scripts > Additional scripts > Scripts for SIMOTION SCOUT Engineering in
Utilities&Applications
to access scripts for making useful standard settings.
SIMOTION SCOUT
Configuration Manual, 11/2016 65
