Programming and Operating Manual (Milling)
150 6FC5398-4DP10-0BA1, 01/2014
Drilling with stop 2 - CYCLE88
Programming
CYCLE88 (RTP, RFP, SDIS, DP, DPR, DTB, SDIR)
RTP REAL Retraction plane (absolute)
RFP REAL Reference plane (absolute)
SDIS REAL Safety clearance (enter without sign)
DP REAL Final drilling depth (absolute)
DPR REAL Final drilling depth relative to the reference plane (enter without sign)
DTB REAL Dwell time at final drilling depth (chip breakage)
SDIR INT Direction of rotation
Values: 3 (for M3), 4 (for M4)
The tool drills at the programmed spindle speed and feedrate to the entered final drilling depth. When drilling with stop, a
spindle stop without orientation M5 and a programmed stop M0 are generated when the final drilling depth is reached.
Pressing the following key traverses the outward movement at rapid traverse until the retraction plane is reached:
Sequence
Position reached prior to cycle start:
The drilling position is the position in the two axes of the selected plane.
The cycle creates the following sequence of motions:
● Approach of the reference plane brought forward by the safety clearance by using G0
● Traversing to final drilling depth with G1 and the feedrate programmed prior to the cycle call
● Dwell time at final drilling depth
● Spindle and program stop with M5 M0. After program stop, press the following key:
● Retraction to the retraction plane with G0
To Next Page
