Pressing this softkey empties the input line of the calculator.
After inputting a desired arithmetic statement in the input line of the calculator, pressing this key starts the
calculation. The result is displayed in the pocket calculator.
Selecting this softkey enters the result in the input field at the current cursor position and closes the
pocket calculator automatically.
Pressing this softkey aborts the calculation result (if any) and exits the pocket calculator.
Characters that may be entered
+, -, *, / Basic arithmetic operations
S Sine function
The X value (in degrees) in front of the input cursor is replaced by the sin(X) value.
O Cosine function
The X value (in degrees) in front of the input cursor is replaced by the cos(X) value.
Q Square function
The X value in front of the input cursor is replaced by the X
2
value.
R Square root function
The X value in front of the input cursor is replaced by the √X value.
( ) Bracket function (X+Y)*Z
Calculation examples
Task
Input -> Result
100 + (67*3) 100+67*3 -> 301
sin(45_) 45 S -> 0.707107
cos(45_) 45 O -> 0.707107
4
2
4 Q -> 16
√4 4 R -> 2
(34+3*2)*10 (34+3*2)*10 -> 400
To calculate auxiliary points on a contour, the pocket calculator offers the following functions:
● Calculating the tangential transition between a circle sector and a straight line
● Moving a point in the plane
● Converting polar coordinates to Cartesian coordinates
● Adding the second end point of a straight line/straight line contour section given from an angular relation
A.13
Calculating contour elements
Function
You can use the calculator to calculate the contour elements in the respective input screens.
