9.6.4
Milling a rectangular spigot - CYCLE76
Programming
CYCLE76 (RTP, RFP, SDIS, DP, DPR, LENG, WID, CRAD, PA, PO, STA, MID, FAL, FALD, FFP1, FFD, CDIR, VARI, AP1,
AP2)
Parameters
Parameter
Data type
Description
RTP REAL Retraction plane (absolute)
RFP REAL Reference plane (absolute)
SDIS REAL Safety clearance (enter without sign)
DP REAL Final drilling depth (absolute)
DPR REAL Final drilling depth relative to the reference plane (enter without sign)
LENG REAL Spigot length
WID REAL Spigot width
CRAD REAL Spigot corner radius (enter without sign)
PA REAL Reference point of spigot, abscissa (absolute)
PO REAL Reference point of spigot, ordinate (absolute)
STA REAL Angle between longitudinal axis and first axis of plane
MID REAL Maximum depth infeed (incremental; enter without sign)
FAL REAL Final machining allowance at the margin contour (incremental)
FALD REAL Finishing allowance at the base (incremental, enter without sign)
FFP1 REAL Feedrate on contour
FFD REAL Feedrate for depth infeed
CDIR INT Milling direction (enter without sign)
Values:
0: Down-cut milling
1: Conventional milling
2: With G2 (independent of spindle direction)
3: With G3
VARI INT Machining type
Values:
1: Roughing to final machining allowance
2: Finishing (allowance X/Y/Z=0)
AP1 REAL Length of blank spigot
AP2 REAL Width of blank spigot
