Siemens SINUMERIK 808D ADVANCED - Entering;Modifying the Tool Wear Data

Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA1, 01/2014
29
3.2.8
Entering/modifying the tool wear data
Note
You must distinguish the direction of tool wear compensation clearly.
Operating sequence
1.
Select the desired operating area.
2.
Open the tool wear window.
3.
Use the cursor keys to select the required tools and their edges.
4.
Enter the tool length wear parameter and the tool radius wear parameter.
Positive value: The tool moves away from the workpiece.
Negative value: The tool moves closer to the workpiece
5.
Press this key or move the cursor to activate the compensation.
