Siemens SINUMERIK 808D ADVANCED Programming And Operating Manual

Programming and Operating Manual (Milling)
228 6FC5398-4DP10-0BA1, 01/2014
5.
Use this key to activate the values after each entry.
You can use the following vertical softkeys to set the reference point to zero:
Set the X axis to zero
Set the Y axis to zero
Set the Z axis to zero
Set the spindle to zero
Set all axes to zero
A.8.2
Face milling
Functionality
Use this function to prepare a blank for the subsequent machining without creating a special part program.
Operating sequence
1. Select the desired operating area.
2. Switch to "JOG" mode.
3. Open the face milling window.
4. Move the cursor keys to navigate in the list and enter the desired values for the selected
parameters (see table below for the parameter descriptions).
5. Confirm your entries with the appropriate key.
6. Select the cutting path of the tool during machining.
