Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA1, 01/2014
43
4. Place the cursor bar on the desired program and press this softkey.
For some directories, press the following softkey instead:
The system automatically changes to "AUTO" mode in the machining operating area after the key
press.
5. If desired, you can use this softkey to specify how you want the program to be executed (for more
information of the program control, refer to Section "Program control (Page 39)").
6. Press this key to start the automatic machining of the program.
Stopping / interrupting a part program
Press this key to stop the execution of a part program. The program currently running is aborted. On the
next program start, the machining starts from the beginning.
Press this key to interrupt the execution of a part program. The axes stop running while the spindle
continues running. On the next program start, the machining is resumed from the interruption point.
Executing / transferring a part program through the RS232 interface
5.5.1
Configuring RS232 communication
Communication tool - SinuComPCIN
To enable the RS232 communication between a SINUMERIK 808D ADVANCED and a PC/PG, you must have the RS232
communication tool SinuComPCIN installed on your PC/PG. This tool is available in the SINUMERIK 808D ADVANCED
Toolbox.
RS232 communication settings
Proceed as follows to configure the communication settings for the RS232 interface:
1. Connect the control system with the PC/PG using an RS232 cable.
Select the desired operating area on the PPU.
Press this softkey to go to the RS232 directory.
Press this softkey to open the window for RS232 communication settings.
Use this key to set the values in the following window as required:
