Addr. Parameter C Setting Options Default Setting Comments
1511 67- IEC CURVE Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1512 67- ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1513A MANUAL CLOSE 67-3 instant.
67-2 instant.
67-1 instant.
67-TOC instant.
Inactive
67-2 instant. Manual Close Mode
1514A 67-2 active with 79 active
always
always 67-2 active
1518A 67 T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 67 Drop-Out Time Delay
1519A ROTATION ANGLE -180 .. 180 ° 45 ° Rotation Angle of Refer-
ence Voltage
1520A 67-2 MEASUREM. Fundamental
True RMS
Fundamental 67-2 measurement of
1521A 67-1 MEASUREM. Fundamental
True RMS
Fundamental 67-1 measurement of
1522A 67-TOC MEASUR. Fundamental
True RMS
Fundamental 67-TOC measurement of
1523 67-2 Direction Forward
Reverse
Non-Directional
Forward 67-2 Direction
1524 67-1 Direction Forward
Reverse
Non-Directional
Forward 67-1 Direction
1525 67-TOC Direct. Forward
Reverse
Non-Directional
Forward 67-TOC Direction
1526 67-3 Direction Forward
Reverse
Non-Directional
Forward 67-3 Direction
1527A 67-3 MEASUREM. Fundamental
True RMS
Fundamental 67-3 measurement of
1528 67-3 PICKUP 1A 1.00 .. 35.00 A; ∞ ∞ A 67-3 Pickup
5A 5.00 .. 175.00 A; ∞ ∞ A
1529 67-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67-3 Time Delay
1530 67 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
67
1531 MofPU Res T/Tp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> T/Tp
Functions
2.3 Directional Overcurrent Protection 67, 67N
102 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
