Siemens SIPROTEC 7SJ80 User Manual

Function Keys
Table E-10 Applies to All Devices and Ordered Variants
Function Keys Default function
F1 Display of the operational indications
F2 Display of the primary operational measured values
F3 Display of the last fault log buffer
F4 not pre-assigned
F5 not pre-assigned
F6 not pre-assigned
F7 not pre-assigned
F8 not pre-assigned
F9 not pre-assigned
E.4
Default Settings and Protocol-dependent Functions
E.4 Function Keys
464 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
