Addr. Parameter C Setting Options Default Setting Comments
1624 67N-1 Direction Forward
Reverse
Non-Directional
Forward 67N-1 Direction
1625 67N-TOC Direct. Forward
Reverse
Non-Directional
Forward 67N-TOC Direction
1626 67N-3 Direction Forward
Reverse
Non-Directional
Forward 67N-3 Direction
1627A 67N-3 MEASUREM. Fundamental
True RMS
Fundamental 67N-3 measurement of
1628 67N-3 PICKUP 0.50 .. 35.00 A; ∞ ∞ A 67N-3 Pickup
1629 67N-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67N-3 Time Delay
1630 M.of PU TD 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Multiples of PU Time-Dial
1631 I/IEp Rf T/TEp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
67N TOC
1632A 67N-3 active always
with 79 active
always 67N-3 active
Information List
No.
Information Type of
Informa-
tion
Comments
2603 67N-3 TRIP OUT 67N-3 TRIP
2604 >BLK 67/67-TOC SP >BLOCK 67/67-TOC
2605 67N-3 BLOCKED OUT 67N-3 is BLOCKED
2606 67-3 BLOCKED OUT 67-3 is BLOCKED
2614 >BLK 67N/67NTOC SP >BLOCK 67N/67N-TOC
2615 >BLOCK 67-2 SP >BLOCK 67-2
2616 >BLOCK 67N-2 SP >BLOCK 67N-2
2617 >BLOCK 67-3 SP >BLOCK 67-3
2618 >BLOCK 67N-3 SP >BLOCK 67N-3
2621 >BLOCK 67-1 SP >BLOCK 67-1
2622 >BLOCK 67-TOC SP >BLOCK 67-TOC
2623 >BLOCK 67N-1 SP >BLOCK 67N-1
2624 >BLOCK 67N-TOC SP >BLOCK 67N-TOC
2628 Phase A forward OUT Phase A forward
2629 Phase B forward OUT Phase B forward
2630 Phase C forward OUT Phase C forward
2632 Phase A reverse OUT Phase A reverse
2633 Phase B reverse OUT Phase B reverse
2634 Phase C reverse OUT Phase C reverse
2635 Ground forward OUT Ground forward
2636 Ground reverse OUT Ground reverse
2637 67-1 BLOCKED OUT 67-1 is BLOCKED
2.3.12
Functions
2.3 Directional Overcurrent Protection 67, 67N
104 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
