Address 664 IP adr[0] (Sec) to 667 IP adr[3]
(Sec)
IP-Addresses 0 to 3, NTP secondary
Address 668 Client activ client for primary and secondary addresses switched
on or off.
Address 669 Daylight Set daylight saving time switched on or off.
Address 670 Offset TZ/min offset for the time zone in minutes
Address 671 Offset DayT/min offset for daylight saving time in minutes
Address 672 W2S month to 675 W2S hour month, week (of the month), day of the week, hour
of switching to daylight saving time
Address 676 S2W month to 679 S2W hour month, week (of the month), day of the week, hour
of switching to winter time
Access authorization for port A
At address 651 ParEN100(LC)blk you can parameterize a read access option via the EN100 module at port
A. If the parameter is set to ON, you can read out the device parameters using DIGSI or fetch fault records.
IEC 61850 GOOSE Function
At address 700 GOOSE-Stop you can set the GOOSE function of the IEC 61850 protocol to active or not. If
GOOSE-Stop is set to YES, you can release the GOOSE function again via a binary input during operation.
Settings
Addr.
Parameter Setting Options Default Setting Comments
610 FltDisp.LED/LCD Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
611 Spont. FltDisp. YES
NO
NO Spontaneous display of flt.annun-
ciations
640 Start image DD image 1
image 2
image 3
image 4
image 5
image 6
image 1 Start image Default Display
651 ParEN100(LC)blk OFF
ON
OFF DIGSI-config. over EN100 (LC)
blocked
660 IP adr[0](Prim) 0 .. 255 0 IP address [0] (NTP-Primary)
661 IP adr[1](Prim) 0 .. 255 0 IP address [1] (NTP-Primary)
662 IP adr[2](Prim) 0 .. 255 0 IP address [2] (NTP-Primary)
663 IP adr[3](Prim) 0 .. 255 0 IP address [3] (NTP-Primary)
664 IP adr[0] (Sec) 0 .. 255 0 IP address [0] (NTP-Sekundary)
665 IP adr[1] (Sec) 0 .. 255 0 IP address [1] (NTP-Sekundary)
666 IP adr[2] (Sec) 0 .. 255 0 IP address [2] (NTP-Sekundary)
667 IP adr[3] (Sec) 0 .. 255 0 IP address [3] (NTP-Sekundary)
668 Client activ OFF
ON
OFF Client activ
669 Daylight Set OFF
ON
OFF Daylight Set
670 Offset TZ/min -1440 .. 1440 min 60 min Offset for time zone in minutes
671 Offset DayT/min -1440 .. 1440 min 60 min Offset for daylight in minutes
2.1.2.3
Functions
2.1 General
SIPROTEC 4, 7SJ80, Manual 35
E50417-G1140-C343-A8, Edition 12.2017
