Addr. Parameter C Setting Options Default Setting Comments
310 Iph-PRIM ref. 10 .. 50000 A 400 A Primary refer. phase
current for prot.
311 Iph-LPCT PRIM 1 .. 5000 A 400 A Rated primary phase
current LPCT
312 Ignd-PRIM ref. 1 .. 50000 A 60 A Primary refer. ground
current for prot.
313 Ignd-LPCT PRIM 0.01 .. 5000.00 A 2.00 A Rated primary ground
current LPCT
314 Vph-LPCT SEC 10.0 .. 1000.0 mV 225.0 mV Rated secondary phase
voltage LPCT
315 Vgnd-LPCT SEC 10.0 .. 1000.0 mV 225.0 mV Rated secondary ground
voltage LPCT
320A Corr.factor IL1 0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL1
321A Corr.factor IL2 0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL2
322A Corr.factor IL3 0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL3
323A Corr.factor IE 0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IE
324A Corr.factor IEE 0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IEE
330 V-LPVT SEC 3.00 .. 17.00 V 3.25 V rated secondary voltage
LPVT
332A V-LPVT PHA -10.00 .. 10.00 ° 0.00 ° phase angle LPVT
613A Gnd O/Cprot. w. Ignd (measured)
3I0 (calcul.)
Ignd (measured) Ground Overcurrent
protection with
614A OP. QUANTITY 59 Vphph
Vph-n
V1
V2
Vphph Opera. Quantity for 59
Overvolt. Prot.
615A OP. QUANTITY 27 V1
Vphph
Vph-n
V1 Opera. Quantity for 27
Undervolt. Prot.
616 STATIC GEN. YES
NO
NO Static or non self-exc. Asyn.
Generator
Information List
No.
Information Type of
Informa-
tion
Comments
5145 >Reverse Rot. SP >Reverse Phase Rotation
5147 Rotation ABC OUT Phase rotation ABC
5148 Rotation ACB OUT Phase rotation ACB
Oscillographic Fault Records
The Multifunctional Protection with Control 7SJ80 is equipped with a fault record memory. The instantaneous
values of the measured values
2.1.3.4
2.1.4
Functions
2.1 General
46 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
