Settings
Addr. Parameter Setting Options Default Setting Comments
8301 DMD Interval 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
8302 DMD Sync.Time On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
Information List
No. Information Type of
Informa-
tion
Comments
833 I1 dmd= MV I1 (positive sequence) Demand
834 P dmd = MV Active Power Demand
835 Q dmd = MV Reactive Power Demand
836 S dmd = MV Apparent Power Demand
963 Ia dmd= MV I A demand
964 Ib dmd= MV I B demand
965 Ic dmd= MV I C demand
Min/Max Measurement Setup
Minimum and maximum values are calculated by the 7SJ80. Time and date of the last update of the values
can also be read out.
Functional Description
Minimum and Maximum Values
The minimum and maximum values for the three phase currents Ι
x
, the three phase-to-ground voltages V
x-N
,
the three phase-to-phase voltages V
xy
, the positive sequence components Ι
1
and V
1
, the displacement voltage
V
0
, the real power P, reactive power Q, and apparent power S, the frequency; and the power factor cos ϕ are
calculated as primary values (including the date and time they were last updated).
The minimum and maximum values of the long-term averages listed in the previous section are also calcu-
lated.
The minimum and maximum values can be reset at any time via binary inputs or by using the integrated
control panel or the DIGSI software. Additionally, the reset can be carried out cyclically, starting at a preset
point of time.
Setting Notes
Minimum and Maximum Values
The tracking of minimum and maximum values can be reset automatically at a programmable point in time.
To select this feature, address 8311 MinMax cycRESET should be set to YES. The point in time when reset is
to take place (the minute of the day in which reset will take place) is set at address 8312 MiMa RESET TIME.
2.23.4.3
2.23.4.4
2.23.5
2.23.5.1
2.23.5.2
Functions
2.23 Auxiliary Functions
SIPROTEC 4, 7SJ80, Manual 293
E50417-G1140-C343-A8, Edition 12.2017
