Addr. Parameter C Setting Options Default Setting Comments
1314A 50N-2 active Always
With 79 Active
Always 50N-2 active
1315A 50N T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 50N Drop-Out Time Delay
1316A 50N-3 active Always
with 79 active
Always 50N-3 active
1317 50N-3 PICKUP 1A 0.25 .. 35.00 A; ∞ ∞ A 50N-3 Pickup
1318 50N-3 DELAY 0.00 .. 60.00 sec; ∞ 0.05 sec 50N-3 Time Delay
1319A 50N-3 measurem. Fundamental
True RMS
Instantaneous
Fundamental 50N-3 measurement of
1320A 50N-2 measurem. Fundamental
True RMS
Fundamental 50N-2 measurement of
1321A 50N-1 measurem. Fundamental
True RMS
Fundamental 50N-1 measurement of
1322A 51N measurem. Fundamental
True RMS
Fundamental 51N measurement of
2201 INRUSH REST. OFF
ON
OFF Inrush Restraint
2202 2nd HARMONIC 10 .. 45 % 15 % 2nd. harmonic in % of
fundamental
2203 CROSS BLOCK NO
YES
NO Cross Block
2204 CROSS BLK TIMER 0.00 .. 180.00 sec 0.00 sec Cross Block Time
2205 I Max 1A 0.30 .. 25.00 A 7.50 A Maximum Current for
Inrush Restraint
5A 1.50 .. 125.00 A 37.50 A
Information List
No.
Information Type of
Informa-
tion
Comments
1704 >BLK 50/51 SP >BLOCK 50/51
1714 >BLK 50N/51N SP >BLOCK 50N/51N
1718 >BLOCK 50-3 SP >BLOCK 50-3
1719 >BLOCK 50N-3 SP >BLOCK 50N-3
1721 >BLOCK 50-2 SP >BLOCK 50-2
1722 >BLOCK 50-1 SP >BLOCK 50-1
1723 >BLOCK 51 SP >BLOCK 51
1724 >BLOCK 50N-2 SP >BLOCK 50N-2
1725 >BLOCK 50N-1 SP >BLOCK 50N-1
1726 >BLOCK 51N SP >BLOCK 51N
1751 50/51 PH OFF OUT 50/51 O/C switched OFF
1752 50/51 PH BLK OUT 50/51 O/C is BLOCKED
1753 50/51 PH ACT OUT 50/51 O/C is ACTIVE
1756 50N/51N OFF OUT 50N/51N is OFF
1757 50N/51N BLK OUT 50N/51N is BLOCKED
1758 50N/51N ACT OUT 50N/51N is ACTIVE
2.2.13
Functions
2.2 Overcurrent Protection 50, 51, 50N, 51N
SIPROTEC 4, 7SJ80, Manual 79
E50417-G1140-C343-A8, Edition 12.2017
