Siemens SIPROTEC 7SJ80 User Manual

Table 2-4 Pickup Indications of Overcurrent Protection
Internal indication Figure Output indication FNo.
50-3 A PU
50-2 A PU
50-1 A PU
51 A PU
Figure 2-4
Figure 2-6
Figure 2-10
50/51 Ph A PU
1762
50-3 B PU
50-2 B PU
50-1 B PU
51 B PU
Figure 2-4
Figure 2-6
Figure 2-10
50/51 Ph B PU
1763
50-3 C PU
50-2 C PU
50-1 C PU
51 C PU
Figure 2-4
Figure 2-6
Figure 2-10
50/51 Ph C PU
1764
50N-3 PU
50N-2 PU
50N-1 PU
51N PU
Figure 2-5
Figure 2-8
Figure 2-11
50N/51NPickedup
1765
50-3 A PU
50-3 B PU
50-3 C PU
50-3 picked up
1767
50N-3 PU
50N-3 picked up
1768
50-2 A PU
50-2 B PU
50-2 C PU
Figure 2-4
Figure 2-4
Figure 2-4
50-2 picked up
1800
50N-2 PU Figure 2-5
50N-2 picked up
1831
50-1 A PU
50-1 B PU
50-1 C PU
Figure 2-6
Figure 2-6
Figure 2-6
50-1 picked up
1810
50N-1 PU Figure 2-5
50N-1 picked up
1834
51 A PU
51 B PU
51 C PU
Figure 2-10
Figure 2-10
Figure 2-10
51 picked up
1820
51N PU Figure 2-11
51N picked up
1837
(All pickups)
50(N)/51(N) PU
1761
In the trip signals, the element which initiated the tripping is also indicated.
Two-phase Overcurrent Protection (Only Non-Directional)
The 2-phase overcurrent protection functionality is used in isolated or grounded systems where interaction
with existing 2-phase protection equipment is required. As an isolated or grounded system remains opera-
tional with a 1-phase ground fault, this protection serves to detect double ground faults with high ground
fault currents. The respective feeder must be switched off only in this case. A 2-phase measurement is suffi-
cient for this purpose. In order to ensure selectivity of the protection in this section of the system, only phases
A and C are monitored.
If 250 50/51 2-ph prot (settable in P.System Data 1) is set to ON, Ι
B
is not used for threshold compar-
ison. If the fault is a simple ground fault in B, the element will not pick up. A double ground fault is assumed
only after pickup on A or C, causing the element to pick up and trip after the delay time has elapsed.
2.2.9
Functions
2.2 Overcurrent Protection 50, 51, 50N, 51N
70 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
