Addr. Parameter C Setting Options Default Setting Comments
2101 67Nc-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 7.00 A 67Nc-2 Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
2102 67Nc-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67Nc-2 Time Delay
2103 67Nc-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 1.50 A 67Nc-1 Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
2104 67Nc-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 67Nc-1 Time Delay
2105 67Nc-TOC PICKUP 1A 0.05 .. 4.00 A 1.00 A 67Nc-TOC Pickup
5A 0.25 .. 20.00 A 5.00 A
2106 67Nc-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 67Nc-TOC Time Dial
2107 67Nc-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67Nc-TOC Time Dial
2108 67Nc-3 PICKUP 0.25 .. 35.00 A; ∞ ∞ A 67Nc-3 Pickup
2109 67Nc-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67Nc-3 Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
1730 >BLOCK CLP SP >BLOCK Cold-Load-Pickup
1731 >BLK CLP stpTim SP >BLOCK Cold-Load-Pickup stop timer
1732 >ACTIVATE CLP SP >ACTIVATE Cold-Load-Pickup
1994 CLP OFF OUT Cold-Load-Pickup switched OFF
1995 CLP BLOCKED OUT Cold-Load-Pickup is BLOCKED
1996 CLP running OUT Cold-Load-Pickup is RUNNING
1997 Dyn set. ACTIVE OUT Dynamic settings are ACTIVE
2.4.4
Functions
2.4 Dynamic Cold Load Pickup
SIPROTEC 4, 7SJ80, Manual 111
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
