Binary Input
Table E-5 Binary input presettings for all devices and ordering variants
Binary Input Default function Function No. Description
BI1 >BLOCK 50-2 1721 >BLOCK 50-2
>BLOCK 50N-2 1724 >BLOCK 50N-2
BI2 >52-b 4602 >52-b contact (OPEN, if bkr is closed)
52Breaker 52 Breaker
BI3 >52-a 4601 >52-a contact (OPEN, if bkr is open)
52Breaker 52 Breaker
Table E-6 Further binary input presettings for 7SJ802* or 7SJ804*
Binary Input Default function Function No. Description
BI4 not pre-assigned - -
BI5 not pre-assigned - -
BI6 not pre-assigned - -
BI7 not pre-assigned - -
Table E-7 Further binary input presettings for 7SJ807* or 7SJ808*
Binary Input Default function Function No. Description
BI4 not pre-assigned - -
BI5 not pre-assigned - -
BI6 not pre-assigned - -
BI7 not pre-assigned - -
BI8 not pre-assigned - -
BI9 not pre-assigned - -
BI10 not pre-assigned - -
BI11 not pre-assigned - -
E.2
Default Settings and Protocol-dependent Functions
E.2 Binary Input
462 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
