Functional Description
Metered Values for Active and Reactive Energy
Metered values of the real power W
p
and reactive power (W
q
) are acquired in kilowatt, megawatt or gigawatt
hours primary or in kVARh, MVARh or GVARh primary, separately according to the input (+) and output (–), or
capacitive and inductive. The measured-value resolution can be configured. The signs of the measured values
appear as configured in address 1108 P,Q sign (see Section “Display of Measured Values”).
Setting Notes
Setting of parameter for meter resolution
Parameter 8315 MeterResolution allows increasing the resolution of the energy metered values by the
Factor 10 or Factor 100 compared to the Standard setting.
Settings
Addr. Parameter Setting Options Default Setting Comments
8315 MeterResolution Standard
Factor 10
Factor 100
Standard Meter resolution
Information List
No.
Information Type of
Informa-
tion
Comments
- Meter res IntSP_Ev Reset meter
888 Wp(puls) PMV Pulsed Energy Wp (active)
889 Wq(puls) PMV Pulsed Energy Wq (reactive)
916 WpΔ= - Increment of active energy
917 WqΔ= - Increment of reactive energy
924 WpForward MVMV Wp Forward
925 WqForward MVMV Wq Forward
928 WpReverse MVMV Wp Reverse
929 WqReverse MVMV Wq Reverse
Commissioning Aids
In test mode or during commissioning, the device information transmitted to a central or storage device can
be influenced. There are tools available for testing the system interface (port B) and the binary inputs and
outputs of the device.
Applications
•
Test Mode
•
Commissioning
Prerequisites
In order to be able to use the commissioning aids described in the following, the device must be connected to
a control center via port B.
2.23.8.1
2.23.8.2
2.23.8.3
2.23.8.4
2.23.9
Functions
2.23 Auxiliary Functions
SIPROTEC 4, 7SJ80, Manual 297
E50417-G1140-C343-A8, Edition 12.2017
