Settings
Addr. Parameter Setting Options Default Setting Comments
8001 START Pickup
TRIP
Pickup Start fault locator with
Information List
No. Information Type of
Informa-
tion
Comments
1106 >Start Flt. Loc SP >Start Fault Locator
1114 Rpri = VI Flt Locator: primary RESISTANCE
1115 Xpri = VI Flt Locator: primary REACTANCE
1117 Rsec = VI Flt Locator: secondary RESISTANCE
1118 Xsec = VI Flt Locator: secondary REACTANCE
1119 dist = VI Flt Locator: Distance to fault
1120 d[%] = VI Flt Locator: Distance [%] to fault
1122 dist = VI Flt Locator: Distance to fault
1123 FL Loop AG OUT Fault Locator Loop AG
1124 FL Loop BG OUT Fault Locator Loop BG
1125 FL Loop CG OUT Fault Locator Loop CG
1126 FL Loop AB OUT Fault Locator Loop AB
1127 FL Loop BC OUT Fault Locator Loop BC
1128 FL Loop CA OUT Fault Locator Loop CA
1132 Flt.Loc.invalid OUT Fault location invalid
2.16.3
2.16.4
Functions
2.16 Fault Locator
234 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
