Accessories
Exchangeable interface modules
Name Order number
RS232 C53207-A351-D641-1
RS485 C53207-A351-D642-1
FO 820 nm C53207-A351-D643-1
Profibus DP RS485 C53207-A351-D611-1
Profibus DP double ring C53207-A351-D613-1
Modbus RS 485 C53207-A351-D621-1
Modbus 820 nm C53207-A351-D623-1
DNP 3.0 RS 485 C53207-A351-D631-1
DNP 3.0 820 nm C53207-A351-D633-1
Ethernet electrical (EN 100) C53207-A351-D675-2
Ethernet optical (EN 100), 4 ST connectors C53207-A351-D678-1
Ethernet electrical (EN 100, PROFINET IO) C53207-A351-D688-1
Ethernet optical (EN 100, PROFINET IO) C53207-A351-D689-1
Ethernet electrical (EN 100, DNP3 TCP ) C53207-A351-D684-1
Ethernet optical (EN 100, DNP3 TCP), multimode C53207-A351-D686-1
Ethernet optical (EN100, DNP3 TCP), single mode, 24 km C53207-A351-D690-1
Ethernet electrical (EN 100, IEC 60870-5-104 ) C53207-A351-D692-1
Ethernet optical (EN 100, IEC 60870-5-104 ) C53207-A351-D693-1
Ethernet electrical (EN 100, Modbus TCP ) C53207-A351-D696-1
Ethernet optical (EN 100, Modbus TCP ) C53207-A351-D697-1
IEC 60870–5–103 protocoll, redundant, RS485 C53207-A351-D644-1
Ethernet port electrical at port A C53207-A351-D151-1
RS485 FO converter
RS485 FO converter
Order No.
820 nm, FC–Connector 7XV5650-0AA00
820 nm, with ST-Connector 7XV5650-0BA00
Mounting Rail for 19"-Racks
Name
Order Number
Mounting Rail Set C73165-A63-D200-1
Surface mounting console (converts flush mounting variants into surface mounting variant)
Surface mounting console
C53207-A356-D850-1
Battery
Lithium battery 3 V/1 Ah, type CR 1/2 AA
Order No.
VARTA 6127 101 301
Panasonic BR-1/2AA
Terminals
Terminals Voltage terminal block C or block E
C53207-A406-D181-1
A.2
Ordering Information and Accessories
A.2 Accessories
SIPROTEC 4, 7SJ80, Manual 431
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
