Functions Pos. 15
Basic design 5)
+ direction determination for phase
+ voltage protection
+ frequency protection
+ synchrocheck
51V Voltage-controlled inverse-time overcurrent protection Q
67 Direction determination for overcurrent phases
67-1, 67- 2, 67-3, 67-TOC
27/59 Undervoltage / overvoltage
81 U/O Underfrequency / overfrequency, f< ,f>
47 Phase sequence
25 Synchronism check
81R/27R/5
9R
Flexible protection functions
(parameters from current and voltage):
Voltage protection, power protection,
power factor protection, frequency change protection
and
voltage change protection
1)
depending on the ground current input at position 7, the function works either as ground fault protection (sensitive
input) or as ground short circuit protection (normal Ie input)
2)
only with sensitive input, Position 7=2
3)
only deliverable with position 6 = 1, 2 or 7
4)
only deliverable with position 6 = 3, 4 (3 x V) or 8
5)
only deliverable with position 6 = 3, 4 (3 x V) or 8 and position 16 = 0 or 1
Automatic reclosing function 79AR / Fault locator 21FL Pos. 16
No 79, no fault locator 0
79 With 79 1
21FL
With fault locator
1)
2
79, 21FL
With AR, with fault locator
1)
3
1)
only deliverable with position 6 = 1, 2 or 7
Conformal Coating Supplementary
for 7SJ801, 7SJ803 +Z Y 15
for 7SJ802, 7SJ804, 7SJ807, 7SJ808 +Z Y 16
Ordering Information and Accessories
A.1 Ordering Information 7SJ80
430 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
