Radio noise voltage to lines, only auxiliary voltage
IEC/CISPR 16-2-1
150 kHz to 30 MHz Limit Class A
Interference field strength
IEC/CISPR 16-2-3
30 MHz bis 1000 MHz Limit Class A
1 GHz to 6 GHz Limit Class A
Harmonic currents on the network lead at AC 230 V
IEC 61000-3-2
Device is to be assigned Class D (applies only to devices
with > 50 VA power consumption)
Voltage dips, interruptions and fluctuations
IEC 60255-11, IEC 61000-4-29
Tolerate Voltage interruptions < 60 ms for the nominal
auxiliary voltage.
Mechanical Tests
Vibration and Shock Stress during Steady-State Operation
Standards: IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2;
IEC 60068-2-6
Sinusoidal
10 Hz to 60 Hz: ±0,075 mm amplitude; 60 Hz bis
150 Hz: 1g acceleration
frequency sweep rate 1 octave/min 20 cycles in 3
orthogonal axes.
Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-27
Semi-sinusoidal
acceleration, duration 11 ms, each 3 shocks in both
directions of the 3 axes
Seismic Vibration
IEC 60255-21-3, Class 2;
IEC 60068-3-3
Sinusoidal
1 Hz to 8 Hz: ±7,5 mm amplitude (horizontal axis)
1 Hz to 8 Hz: ±3,5 mm amplitude (vertical axis)
8 Hz to 35 Hz: 2 g acceleration (horizontal axis)
8 Hz to 35 Hz: 1 g acceleration (vertical axis)
Frequency sweep 1 octave/min
1 cycle in 3 orthogonal axes
Vibration and Shock Stress during Transport
Standards:
IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2;
IEC 60068-2-6
Sinusoidal
5 Hz to 8 Hz: ±7.5 mm amplitude;
8 Hz to 150 Hz: 2 g acceleration
frequency sweep 1 octave/min
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-27
Semi-sinusoidal
15 g acceleration, duration 11 ms,
each 3 shocks (in both directions of the 3 axes)
Continuous Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-29
Semi-sinusoidal
10 g acceleration, duration 16 ms,
each 1000 shocks (in both directions of the 3 axes)
Climatic Stress Tests
Temperatures
Standards:
IEC 60255-1, IEC 60068-2-1/2, IEC 60068-2-78, IEC
60068-2-30
4.1.6
4.1.7
Technical Data
4.1 General Device Data
360 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
