Addr. Parameter Setting Options Default Setting Comments
672 W2S month 1 .. 12 3 month of time set winter to
summer
673 W2S week 1 .. 5 5 week of time set winter to
summer
674 W2S day Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Sunday day of time set winter to summer
675 W2S hour 1 .. 24 2 hour of time set winter to summer
676 S2W month 1 .. 12 10 month of time set summer to
winter
677 S2W week 1 .. 5 5 week of time set summer to
winter
678 S2W day Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Sunday day of time set summer to winter
679 S2W hour 1 .. 24 3 hour of time set summer to winter
700 GOOSE-Stop YES
NO
NO GOOSE-Stop
Information List
No.
Information Type of
Informa-
tion
Comments
- >Light on SP >Back Light on
- Reset LED IntSP Reset LED
- DataStop IntSP Stop data transmission
- Test mode IntSP Test mode
- Feeder gnd IntSP Feeder GROUNDED
- Brk OPENED IntSP Breaker OPENED
- HWTestMod IntSP Hardware Test Mode
- SynchClock IntSP_Ev Clock Synchronization
- Distur.CFC OUT Disturbance CFC
1 Not configured SP No Function configured
2 Non Existent SP Function Not Available
3 >Time Synch SP_Ev >Synchronize Internal Real Time Clock
5 >Reset LED SP >Reset LED
15 >Test mode SP >Test mode
16 >DataStop SP >Stop data transmission
51 Device OK OUT Device is Operational and Protecting
52 ProtActive IntSP At Least 1 Protection Funct. is Active
