Ordering Information 7SJ80
Multifunctional
protection device
with control
6 7 8 9 10 11 12 13 14 15 16 Zusatz
7 S J 8 0 – – F +
Number of binary inputs and outputs Pos. 6
Housing 1/6 19” 4 x Ι, 3 BI, 5 BO (2 changeover contacts), 1 life status contact
1
Housing 1/6 19” 4 x Ι, 7 BI, 8 BO (2 changeover contacts), 1 life status contact
2
Housing 1/6 19” 4 x Ι, 3x V, 3 BI, 5 BO (2 changeover contacts), 1 life status contact
3
Housing 1/6 19” 4 x Ι, 3 x V, 7 BI, 8 BO (2 changeover contacts), 1 life status contact
4
Housing 1/6 19” 4 x Ι, 11 BI, 5 BO (2 changeover contacts), 1 life status contact
7
Housing 1/6 19” 4 x Ι, 3 x V, 11 BI, 5 BO (2 changeover contacts), 1 life status contact
8
Measuring inputs (4 x Ι)
Pos. 7
Ι
ph
= 1 A, Ι
e
= 1 A / 5 A
1
Ι
ph
= 1 A, Ι
ns
(sensitive) = 0.001 A to 1.6 A / 0.005 A to 8 A
2
Auxiliary voltage (power supply, pilot voltage) Pos. 8
DC 24 V/ 48 V 1
DC 60 V / 110 V / 125 V / 220 V / 250 V, AC 115 V, AC 230 V 5
Construction Pos. 9
Surface-mounting case, screw-type terminals B
Flush mounting case, screw-type terminals E
Region-specific default settings / function versions and language default settings Pos. 10
Region DE, IEC, language German (language can be changed, standard front panel A
Region world, IEC/ANSI, language English (language can be changed), standard front panel B
Region US, ANSI, language US-English (language can be changed), US front panel C
Region FR, IEC/ANSI, language French (language can be changed), standard front panel D
Region world, IEC/ANSI, language Spanish (language can be changed), standard front panel E
Region world, IEC/ANSI, language Italian (language can be changed), standard front panel F
Region RUS, IEC/ANSI, language Russian (language can be changed), standard front panel G
Region CHN, IEC/ANSI, language Chinese (language can not be changed), standard front panel Chinese K
Port B (bottom side of device, rear) Pos. 11
not equipped 0
IEC60870-5-103 or DIGSI4/Modem, electrical RS232 1
IEC60870-5-103 or DIGSI4/Modem, electrical RS485 2
IEC60870-5-103 or DIGSI4/Modem, optical 820nm, ST connector 3
For further interface options see Additional Information in the following 9
Additional information for additional ports (bottom side of device, rear, port B) Supple-
mentary
Profibus DP Slave, electrical RS485 + L 0 A
Profibus DP Slave, 820 nm, optical double ring, ST connector + L 0 B
Modbus, electrical RS485 + L 0 D
Modbus, optical 820 nm, ST connector + L 0 E
DNP3.0, electrical RS485 + L 0 G
DNP3.0, optical 820 nm, ST connector + L 0 H
A.1
Ordering Information and Accessories
A.1 Ordering Information 7SJ80
426 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
