Additional information for additional ports (bottom side of device, rear, port B) Supple-
mentary
IEC 60870-5-103 Protocol, redundant, electrical RS485, RJ45 connector + L 0 P
IEC 61850, 100Mbit Ethernet electrical, double, RJ45 connector + L 0 R
IEC 61850 100 Mbit Ethernet optical, double, LC connector + L 0 S
DNP3 TCP, 100 Mbit Ethernet electrical, double, RJ45 connector + L 2 R
DNP3 TCP, 100 Mbit Ethernet optical, double, LC connector + L 2 S
PROFINET 100Mbit Ethernet electrical, double, RJ45 connector + L 3 R
PROFINET 100 Mbit Ethernet optical, double, LC connector + L 3 S
IEC 60870-5-104 and IEC 61850, 100Mbit Ethernet, electrical, double, RJ45 connector + L 4 R
IEC 60870-5-104 and IEC 61850, 100Mbit Ethernet, optical, double, LC connector + L 4 S
MODBUS TCP and IEC 61850, 100Mbit Ethernet, electrical, double, RJ45 connector + L 5 R
MODBUS TCP and IEC 61850, 100Mbit Ethernet, optical, double, LC connector + L 5 S
Converter Order number Use
SIEMENS OLM
1)
6GK1502–2CB10 for single ring
SIEMENS OLM
1)
6GK1502–3CB10 for double ring
1)
The converter requires an operating voltage of 24 VDC. If the available operating voltage is > 24 VDC the
additional power supply 7XV5810–0BA00 is required.
Port A (bottom side of device, front) Pos. 12
not equipped 0
with Ethernet interface (DIGSI interface, I/O unit connection, not IEC61850), RJ45 connector 6
Measurement / Fault Recording Pos. 13
With fault recording 1
With fault recording, average values, min/max values 3
Ordering Information and Accessories
A.1 Ordering Information 7SJ80
SIPROTEC 4, 7SJ80, Manual 427
E50417-G1140-C343-A8, Edition 12.2017
