Individual element Number of TICKS
Additionally for each chart 1
Arithmetic ABS_VALUE 5
ADD 26
SUB 26
MUL 26
DIV 54
SQUARE_ROOT 83
Base logic AND 5
CONNECT 4
DYN_OR 6
NAND 5
NEG 4
NOR 5
OR 5
RISE_DETECT 4
X_OR 5
Information status SI_GET_STATUS 5
CV_GET_STATUS 5
DI_GET_STATUS 5
MV_GET_STATUS 5
SI_SET_STATUS 5
DI_SET_STATUS 5
MV_SET_STATUS 5
ST_AND 5
ST_OR 5
ST_NOT 5
Memory D_FF 5
D_FF_MEMO 6
RS_FF 4
RS_FF_MEMO 4
SR_FF 4
SR_FF_MEMO 4
Control commands BOOL_TO_CO 5
BOOL_TO_IC 5
CMD_INF 4
CMD_INF_EXE 4
CMD_CHAIN 34
CMD_CANCEL 3
LOOP 8
Type converter BOOL_TO_DI 5
BUILD_DI 5
DI_TO_BOOL 5
DM_DECODE 8
DINT_TO_REAL 5
DIST_DECODE 8
UINT_TO_REAL 5
REAL_TO_DINT 10
Technical Data
4.22 User-defined Functions (CFC)
414 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
