Addr. Parameter Function C Setting Options Default Setting Comments
204 CT PRIMARY P.System Data
1
10 .. 50000 A 400 A CT Rated Primary Current
205 CT SECONDARY P.System Data
1
1A
5A
1A CT Rated Secondary
Current
206A Vph / Vdelta P.System Data
1
1.00 .. 3.00 1.73 Matching ratio Phase-VT
To Open-Delta-VT
207 Vol. Symmetry P.System Data
1
NO
YES
NO Assumption voltage
symmetry
209 PHASE SEQ. P.System Data
1
A B C
A C B
A B C Phase Sequence
210A TMin TRIP CMD P.System Data
1
0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command
Duration
211A TMax CLOSE CMD P.System Data
1
0.01 .. 32.00 sec 1.00 sec Maximum Close
Command Duration
212 BkrClosed I MIN P.System Data
1
1A 0.04 .. 1.00 A 0.04 A Closed Breaker Min.
Current Threshold
5A 0.20 .. 5.00 A 0.20 A
213 VT Connect. 3ph P.System Data
1
Van, Vbn, Vcn
Vab, Vbc, VGnd
Vab, Vbc, VSyn
Vab, Vbc
Vph-g, VSyn
Vab, Vbc, Vx
Van, Vbn, Vcn VT Connection, three-
phase
214 Rated Frequency P.System Data
1
50 Hz
60 Hz
50 Hz Rated Frequency
215 Distance Unit P.System Data
1
km
Miles
km Distance measurement
unit
217 Ignd-CT PRIM P.System Data
1
1 .. 50000 A 60 A Ignd-CT rated primary
current
218 Ignd-CT SEC P.System Data
1
1A
5A
1A Ignd-CT rated secondary
current
220 Threshold BI 1 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
1
221 Threshold BI 2 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
2
222 Threshold BI 3 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
3
223 Threshold BI 4 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
4
224 Threshold BI 5 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
5
225 Threshold BI 6 P.System Data
1
Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input
6
Functions, Settings, Information
F.2 Settings
