Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
5001 FCT 59 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 59 Overvoltage Protec-
tion
5002 59-1 PICKUP 27/59 O/U Volt. 20 .. 260 V 110 V 59-1 Pickup
5003 59-1 PICKUP 27/59 O/U Volt. 20 .. 150 V 110 V 59-1 Pickup
5004 59-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
0.50 sec 59-1 Time Delay
5005 59-2 PICKUP 27/59 O/U Volt. 20 .. 260 V 120 V 59-2 Pickup
5006 59-2 PICKUP 27/59 O/U Volt. 20 .. 150 V 120 V 59-2 Pickup
5007 59-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
0.50 sec 59-2 Time Delay
5015 59-1 PICKUP V2 27/59 O/U Volt. 2 .. 150 V 30 V 59-1 Pickup V2
5016 59-2 PICKUP V2 27/59 O/U Volt. 2 .. 150 V 50 V 59-2 Pickup V2
5017A 59-1 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-1 Dropout Ratio
5018A 59-2 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-2 Dropout Ratio
5019 59-1 PICKUP V1 27/59 O/U Volt. 20 .. 150 V 110 V 59-1 Pickup V1
5020 59-2 PICKUP V1 27/59 O/U Volt. 20 .. 150 V 120 V 59-2 Pickup V1
5101 FCT 27 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 27 Undervoltage Protec-
tion
5102 27-1 PICKUP 27/59 O/U Volt. 10 .. 210 V 75 V 27-1 Pickup
5103 27-1 PICKUP 27/59 O/U Volt. 10 .. 120 V 45 V 27-1 Pickup
5106 27-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
1.50 sec 27-1 Time Delay
5110 27-2 PICKUP 27/59 O/U Volt. 10 .. 210 V 70 V 27-2 Pickup
5111 27-2 PICKUP 27/59 O/U Volt. 10 .. 120 V 40 V 27-2 Pickup
5112 27-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
0.50 sec 27-2 Time Delay
5113A 27-1 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-1 Dropout Ratio
5114A 27-2 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-2 Dropout Ratio
5120A CURRENT SUPERV. 27/59 O/U Volt. OFF
ON
ON Current Supervision
5201 VT BROKEN WIRE Meas-
urem.Superv
ON
OFF
OFF VT broken wire supervi-
sion
5202 Σ V> Meas-
urem.Superv
1.0 .. 100.0 V 8.0 V Threshold voltage sum
5203 Vph-ph max< Meas-
urem.Superv
1.0 .. 100.0 V 16.0 V Maximum phase to phase
voltage
5204 Vph-ph min< Meas-
urem.Superv
1.0 .. 100.0 V 16.0 V Minimum phase to phase
voltage
5205 Vph-ph max-min> Meas-
urem.Superv
10.0 .. 200.0 V 16.0 V Symmetry phase to phase
voltages
5206 I min> Meas-
urem.Superv
1A 0.04 .. 1.00 A 0.04 A Minimum line current
5A 0.20 .. 5.00 A 0.20 A
5208 T DELAY ALARM Meas-
urem.Superv
0.00 .. 32.00 sec 1.25 sec Alarm delay time
5301 FUSE FAIL MON. Meas-
urem.Superv
OFF
Solid grounded
Coil.gnd./isol.
OFF Fuse Fail Monitor
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7SJ80, Manual 489
E50417-G1140-C343-A8, Edition 12.2017
