Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
6014 S2: x' P.System Data
2
1A 0.0050 ..
9.5000 Ω/km
0.1500 Ω/km S2: feeder reactance per
km: x'
5A 0.0010 ..
1.9000 Ω/km
0.0300 Ω/km
6015 S2: Line angle P.System Data
2
10 .. 89 ° 85 ° S2: Line angle
6016 S2: Line length P.System Data
2
0.1 .. 650.0 Miles 62.1 Miles S2: Line length in miles
6017 S2: Line length P.System Data
2
0.1 .. 1000.0 km 100.0 km S2: Line length in kilo-
meter
6021 S3: RE/RL P.System Data
2
-0.33 .. 7.00 1.00 S3: Zero seq. compen-
sating factor RE/RL
6022 S3: XE/XL P.System Data
2
-0.33 .. 7.00 1.00 S3: Zero seq. compen-
sating factor XE/XL
6023 S3: x' P.System Data
2
1A 0.0050 ..
15.0000 Ω/mi
0.2420 Ω/mi S3: feeder reactance per
mile: x'
5A 0.0010 ..
3.0000 Ω/mi
0.0484 Ω/mi
6024 S3: x' P.System Data
2
1A 0.0050 ..
9.5000 Ω/km
0.1500 Ω/km S3: feeder reactance per
km: x'
5A 0.0010 ..
1.9000 Ω/km
0.0300 Ω/km
6025 S3: Line angle P.System Data
2
10 .. 89 ° 85 ° S3: Line angle
6026 S3: Line length P.System Data
2
0.1 .. 650.0 Miles 62.1 Miles S3: Line length in miles
6027 S3: Line length P.System Data
2
0.1 .. 1000.0 km 100.0 km S3: Line length in kilo-
meter
6101 Synchronizing SYNC function
1
ON
OFF
OFF Synchronizing Function
6102 SyncCB SYNC function
1
(Einstellmöglich-
keiten anwendung-
sabhängig)
none Synchronizable circuit
breaker
6103 Vmin SYNC function
1
20 .. 125 V 90 V Minimum voltage limit:
Vmin
6104 Vmax SYNC function
1
20 .. 140 V 110 V Maximum voltage limit:
Vmax
6105 V< SYNC function
1
1 .. 60 V 5 V Threshold V1, V2 without
voltage
6106 V> SYNC function
1
20 .. 140 V 80 V Threshold V1, V2 with
voltage
6107 SYNC V1<V2> SYNC function
1
YES
NO
NO ON-Command at V1< and
V2>
6108 SYNC V1>V2< SYNC function
1
YES
NO
NO ON-Command at V1> and
V2<
6109 SYNC V1<V2< SYNC function
1
YES
NO
NO ON-Command at V1< and
V2<
6110A Direct CO SYNC function
1
YES
NO
NO Direct ON-Command
6111A TSUP VOLTAGE SYNC function
1
0.00 .. 60.00 sec 0.10 sec Supervision time of
V1>;V2> or V1<;V2<
Functions, Settings, Information
F.2 Settings
492 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
