No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
7556 InRush OFF (InRush OFF) 50/51
Overcur.
OUT On
Of
f
* * LED BO 60 92 1 Yes
7557 InRush BLOCKED (InRush
BLK)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 93 1 Yes
7558 InRush Ground detected
(InRush Gnd Det)
50/51
Overcur.
OUT * On
Off
* LED BO 60 94 2 Yes
7559 67-1 InRush picked up
(67-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 84 2 Yes
7560 67N-1 InRush picked up
(67N-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 85 2 Yes
7561 67-TOC InRush picked up
(67-TOC InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 86 2 Yes
7562 67N-TOC InRush picked
up (67N-TOCInRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 87 2 Yes
7563 >BLOCK InRush (>BLOCK
InRush)
50/51
Overcur.
SP * * * LED BI BO
7564 Ground InRush picked up
(Gnd InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 88 2 Yes
7565 Phase A InRush picked up
(Ia InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 89 2 Yes
7566 Phase B InRush picked up
(Ib InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 90 2 Yes
7567 Phase C InRush picked up
(Ic InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 91 2 Yes
10034 50-3 BLOCKED (50-3
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 16
9
1 Yes
10035 50N-3 BLOCKED (50N-3
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 17
0
1 Yes
10080 Error Extension I/O (Error
Ext I/O)
Device,
General
OUT On
Of
f
* * LED BO
10081 Error Ethernet (Error
Ethernet)
Device,
General
OUT On
Of
f
* * LED BO
10082 Error Current Terminal
(Error Terminal)
Device,
General
OUT On
Of
f
* * LED BO
10083 Error Basic I/O (Error Basic
I/O)
Device,
General
OUT On
Of
f
* * LED BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ80, Manual 535
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
