Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
96
S/N
Monitoring Parameter Variable
100% full-scale output
14
Speed adjuster deviation
Upper limiting frequency*60/pairs of motor poles
15
Speed adjuster output
300.0%
16
Process PID setting
100.0%
17
Process PID feedback
100.0%
18
Process PID deviation value
200.0%
19
Process PID output
100.0%
20
Compensation PID setting
100.0%
21
Compensation PID feedback
100.0%
22
Compensation PID deviation
200.0%
23
Compensation PID output
100.0%
24
AI1 input (0.00~10.00)
10.00 V
25
AI2 input (0.00~20.00)
20.00mA
26
AI3 input (-10.00~10.00)
10.00V
27
Fin input
Maximum input frequency
28
Current liner speed (Fin calculation)
Maximum permitted liner speed
29
Accumulative counted length ( liner speed
accumulation)
Maximum counted length
30
Counter 1 value
Counter 1 set value 2
31
Counter 2 value
Counter 2 set value 2
32
Timer 1 value
Timer 1 timing cycle
33
Timer 2 value
Timer 2 timing cycle
34
Timer 3 value
Timer 3 timing cycle
35
Built-in Fieldbus set value 1
10000
36
Extended communication module set value 1
10000
37
Built-in Fieldbus set value 2
30000
38
Extended communication module set value 2
30000
39~44
Reserve
45
Fixed output (current or voltage)
20.00mA (10.00V)
