Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
95
S/N
Function
S/N
Function
40
Counter 1 output signal 1
41
Counter 1 output signal 2
42
Counter 2 output model 1
43
Counter 2 output signal 2
44
Timer 1 output signal 1
45
Timer 1 output signal 2
46
Timer 2 output signal 1
47
Timer 2 output signal 2
48
Timer 3 output signal 1
49
Timer 3 output signal 2
50
Extension modules retained
51
Extension modules retained
52
Extension modules retained
53
Extension modules retained
54
Extension modules retained
55
DI1 terminal status effective
56
DI2 terminal status effective
57
DI3 terminal status effective
58
DI4 terminal status effective
59
DI5 terminal status effective
60
DI6 terminal status effective
61
DI7 terminal status effective
62
DI8 terminal status effective
63
Terminal as frequency output (only applicable to
DO3/FO terminal)
64
SDO1 LDI
65
SDO2 LDI
66
SDO1⊙SDO2 AND
67
SDO3⊙SDO4 AND
68
SDO5⊙SDO6 AND
69
SDO3⊕SDO4 OR
70
SDO5⊕SDO6 OR
71
SDO7⊕SDO8 OR
Table 3: Comparison Table of Monitor Variables
S/N
Monitoring Parameter Variable
100% full-scale output
0
Output frequency (rotor synchronous frequency)
Upper limiting frequency
1
Motor Revolution
Upper limiting frequency*60/pairs of motor poles
2
Output current
250%*Inverter rated current
3
Output torque
300% rated torque
4
Output voltage
Motor rated voltage (reference voltage in V/F
mode)
5
Output power
2* motor rated power
6
Maximum temperature of the equipment
150.0°C
7
Voltage at the DC side
1000V (single phase 500V)
8
Motor temperature/ PTC resistance
500.0°C / 5000Ω
9
Frequency setting channel set value
Upper limiting frequency
10
Speed command
Upper limiting frequency*60/pairs of motor poles
11
Torque command
300% rated torque
12
Target operating frequency
Upper limiting frequency
13
Reserved
——

Direction will not be considered for comparison of monitor variables
