140
Description Of Specific Functions
V800 Series High Performance Closed-Loop Vector Inverter User Manual
69: Servo control effective
Switching terminal of servo control and moment of force control (relative function parameter Fb.2.23).
70: Spindle positioning origin photoelectric signal input
When reference signal of spindle positioning origin is photoelectric switch positioning (parameter Fb.2.36),
this signal stands for spindle origin.
71: Spindle origin homing
When this function is valid, spindle auto positions to origin position to maintain the moment of force, and after
the signal is cancelled, there is no moment of force output.
72: Spindle positioning selection 1
73: Spindle positioning selection 2
74: Spindle positioning selection 3
When the spindle positioning command selects external terminal selecting source(relative function
parameter Fb.2.36), these multi-function terminal are used for spindle positioning angle selecting, when the
following groups are valid, the spindle positions to the assigned angle and maintains the moment of force.
When these terminals are invalid, there is no moment of force output.
Table 7-15 Selecting table for spindle positioning angle
Spindle positioning
selection 3
Spindle positioning
selection 2
Spindle positioning
selection 1
Positioning angle values
OFF
OFF
OFF
Common operation
OFF
OFF
ON
Positioning angle1 (Fb.2.38)
OFF
ON
OFF
Positioning angle 2 (Fb.2.39)
OFF
ON
ON
Positioning angle 3 (Fb.2.40)
ON
OFF
OFF
Positioning angle 4 (Fb.2.41)
ON
OFF
ON
Positioning angle 5 (Fb.2.42)
ON
ON
OFF
Positioning angle 6 (Fb.2.43)
ON
ON
ON
Positioning angle 7 (Fb.2.44)
75: Position gain selection
Position gain of servo control or spindle positioning selecting.
76: Reserved
77: Servo command pulse value zero clearing
78~96: Reservation function
97: Pulse input (0.1~100.00 KHz)
This function is applied to multi-function input terminal DI9/Fin (F3.0.08), and 0.10~100.00 KHz signal can be
received effectively.
98: Pulse input
This function is applied to multi-function input terminal DI9/Fin (F3.0.08) and 1.0~1000.0 KHz low frequency
signal can be received effectively.
F3.0.09 Multifunctional terminal filtering
time (DI1~DI5)
Setting range: 1~50ms
Factory default: 5
F3.0.10 Multifunctional terminal filtering
time (DI6~DI9) /standard expansion card
Setting range: 1~50ms
Factory default: 5
Set the filtering time of the input terminal detection. When state of the input terminal changes, if it remains the
