same even after the filtering time setting, the terminal state change is effective, or otherwise it will remains
the former state, thus the interference triggered false operation can be reduced.
F3.0.11 Input terminal effective
level (H)
Setting range: 0000~0FFF
Factory default: 0000
Define the positive and negative logic of the input terminal.
Positive logic: When DIx terminal and common port COM are connected, it is valid, or otherwise it is invalid.
Negative logic: When DIx terminal and common port COM are disconnected, it is valid, or otherwise it is
invalid.
Bit place as 0 represents the positive logic; 1 represents negative logic.
Determination methods of parameter setting value are shown as following:
Table 7-16 Correspondence between Binary Number Setting and Digital Show Value
Binary number setting
Hexadecimal(digital show value)
BIT3
BIT2
BIT1
BIT0
0
0
0
0
0
0
0
0
1
1
0
0
1
0
2
0
0
1
1
3
0
1
0
0
4
0
1
0
1
5
0
1
1
0
6
BIT0:Positive and negative logic definition of
D11；
BIT2:Positive and negative logic definition of
D12；
BIT3:Positive and negative logic definition of
D13；
BIT4:Positive and negative logicdefinition of
D14；
BIT0:Positive and negative logic definition of
D15；
BIT2:Positive and negative logic definition of
D16；
BIT3:Positive and negative logic definition of
D17；
BIT4:Positive and negative logic definition of
D18；
BIT0:Positive and negative logic definition of
D19
Reserve
Kilobit Hundreds
Tens
The unit
