Simrad ST90 User Manual

457420/A
117
TheOperatingPanelpageisusedtoselectwhichphysicalhardwarepanelyouuseonyour
ST90,andtoassignfunctionalitytotheprogrammablebuttons.Thispageislocatedinthe
Installationdialogbox.TheInstallationdialogboxislocatedontheSetupmenu.
Note
TheST90supportstwodifferentoperatingpanels.Thesearereferredtoas"Mk1"and
"Mk2".Inthispublicationalldescriptionsandreferencesarerelatedto"Mk2".
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationmenuopens.This
dialogboxcontainsanumberofpagesselected
fromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4SelectOperatingPanelMk2.
5UnderUserSettingButtons,assignonepredenedsettingtoeachbuttononthe
OperatingPanel.
6Atthebottomofthepage,selectApplytosaveyoursettings.
7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Relatedtopics
Deningtheuser-selectedfeaturesontheOperatingPanel,page115
Operatingprocedures
