Simrad ST90 User Manual

457420/A
119
7ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Relatedtopics
Deningtheuser-selectedfeaturesontheOperatingPanel,page115
AssigningfunctionstoF1,F2andF3ontheOperatingPanel
TheOperatingPanelisttedwiththreefunctionbuttons.ThebuttonsareidentiedasF1,F2
andF3.Eachbuttoncanbeassignedadedicatedfunction.
Context
TheOperatingPanelpageisusedtoselectwhichphysical
hardwarepanelyouuseonyourST90,andtoassign
functionalitytotheprogrammablebuttons.Thispage
islocatedintheInstallationdialogbox.TheInstallation
dialogboxislocatedontheSetupmenu.
ThethreefunctionbuttonsaregroupedwiththeScreen
Capturebutton.
Note
TheST90supportstwodifferentoperatingpanels.These
arereferredtoas"Mk1"and"Mk2".Inthispublicationall
descriptionsandreferencesarerelatedto"Mk2".
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationmenuopens.Thisdialogboxcontainsanumberofpages
selectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectOperatingPanel.
4Selectwhichoperatingpaneltouse.
5UnderButtonOptions,assignonefunctiontoeachFxbuttonontheOperatingPanel.
Thefollowingfunctionscanbecontrolled:
•AutoTilt:Thisisan"on/off"function.InAutoTiltmodethebeamautomatically
changesthetiltangleforeachping.Thecentreofthetiltsectorisdenedbythe
Operatingprocedures
