Simrad ST90 User Manual

90
457420/A
Note
Thedataleswillnormallybecomeverylarge.Ifyouwishtorecordlargeamountsof
ST90data,makesurethatyouhaveenoughspaceonyourharddisk.TheST90isnot
providedwithunlimiteddiskcapacity.Werecommendthatyousavethedatalestoan
externalstoragedevice.
Procedure
1OpentheOperationmenu.
2Tostartdatarecording,opentheRecordbutton,andselectOn.
or:
Tostartrecording,selecttheredcircleontherightsideofthebutton.
TheRecordindicatoronthetopbarchangesitscolourtoreectthatrecordingisactive.
3Tostoprecording,opentheRecordbutton,andselectOff.
Alternatively,selecttheblackrectangleontheleftsideofthebuttontostopthe
recording.
Relatedtopics
Recordingandreplayingechodata,page88
SelectingReplaymode
Replaymodeallowsyoutoplaybackpreviouslyrecordedrawdata.TheST90cannot
operatenormallywhileinReplaymode.Neithertransmissionnorreceptiontakesplace.
Context
Allplaybackiscontrolledbythereplaybar.
AStop:Selectthisbuttontostoptheplayback.
BPlay/Pause:Selectthisbuttontostarttheplayback,ortopauseit.
CReplaySpeed:Selectthissliderandmoveitsidewaystoadjustthereplayspeed.
