ReducingnoiseandfalseechoeswiththePing-PingFilter
ThePing-PingFilteranalysesthehistoricalinformationfrompreviousconsecutivepingsin
ordertoremoveunwantednoiseandfalseechoesfromtheST90presentation.
Context
Thefollowinglteroptionsareprovided.
•Off:SelectOfftodisablethelter.Thehistoricalinformationfromprevioustransmissions
("pings")arenotusedtoremovenoiseandunwantedechoes.
•Weak:SelectWeaktoallowtheltertocomparetheechoesfromthelatesttwopings.
Forthecurrentechotobeshown,itmustbepresentinbothofthesepings.
•Medium:ChooseMediumtocomparetheechoesfromthelatestfourpings.Forthe
currentechotobeshown,itmustbepresentinallofthesepings.
•Strong:SelectStrongtoallowtheltertocomparetheechoesfromthelatesteightpings.
Forthecurrentechotobeshown,itmustbepresentinalloftheseeightpings.
TheltersintheST90areimplementedin“series”.ThePing-PingFilteristhelastlterin
thesequence,soanychangestotheotherltersmayhaveaneffectonhowitworks.
Procedure
1Clickinanyviewtomakeitactive.
Theactiveviewisidentiedwithathickerborder.
2OpentheActivemenu.
3SelectPing-PingFilter.
4Choosetherequiredsetting.
Thechoiceyoumakeisbydefaultonlyappliedtothecurrentlyselected(active)view.
