457420/A

3ObservetheMainmenu.

ItsdefaultlocationisontherightsideoftheST90presentation.

4SelectTilt.

5Makethenecessaryadjustment.

Selecteithersideofthebuttontochooseavalue.Keepthemousebuttondepressedto

changethevaluefaster.

or:

Placethecursoronthebutton.Pressandholdtheleft mousebutton.Movethecursor

horizontallyoverthebutton.Releasethemousebuttonwhenrequestedvalueisshown.

or:

Selectthemiddleofthebuttontoopenit.Ifyouhaveakeyboardconnectedtothe

ST90,youcantypetherequestedvalue.

6OpenthebuttonandselectApplytoallifyouwishtousethechosensettinginallthe

viewsinthecurrentpresentationmode.

Relatedtopics

Controllingthegainandrangesettings,page61

Adjustingthebearing

TheHorizontalviewintheST90presentationcoverstheentire360°omnidirectionalsector

Fortheotherviewsyoumustdenethehorizontaldirectionofthebeam.

Context

IntheHorizontalviewthecurrentbearingisshownwithacontinuouslinepointingout

fromthevesselposition.Theareacoveredbytheverticalbeamisshownasatrianglein

theHorizontalview.

Note

Thechoiceyoumakeisbydefaultonlyappliedtothecurrentlyselected(active)view.The

activeviewisidentiedwithathickerborder.

Anewtrackedobjectisautomaticallygivenprioritystatus.Thepriorityisidentiedwitha

"P".Thebearingandtiltsettingsareautomaticallyadjustedtofollowthemovementsofthe

trackedtarget.Thebearinglineisautomaticallylockedontheobjecttoreectsitsbearing.

Operatingprocedures
