78
457420/A
Improvingtherecognitionofshandschools
usingreceiverlters
Topics
AboutthereceiverltersequenceintheST90,page78
ReducingnoiseandreverberationwiththeAGC(AutomaticGainControl)function,page79
ReducingpropellernoiseandinterferencewiththeNoiseFilter,page81
ReducingbottomandsurfacereverberationwiththeRCG(ReverberationControlledGain)
function,page82
ReducingnoiseandfalseechoeswiththePing-PingFilter,page84
Adjustingtheintensityoftheechopresentations,page86
AboutthereceiverltersequenceintheST90
TheltersintheST90areimplementedin“series”.Anychangestoaltersettingmay
thereforehaveaneffectonsubsequentlters.
ABottomFilter
BNoiseFilter(1)
CGain&TVG(TimeVariableGain)
DNoiseFilter(2)
EAGC(AutomaticGainControl)
FRCG(ReverberationControlledGain)
GDisplayGain
HPing-PingFilter
