Simrad ST90 - Adjusting the Horizontal Direction of the Sonar Beam

457420/A
37
or:
Placethecursoronthebutton.Pressandholdtheleft
mousebutton.Movethecursor
horizontallyoverthebutton.Releasethemousebuttonwhenrequestedvalueisshown.
or:
Selectthemiddleofthebuttontoopenit.Ifyouhaveakeyboardconnectedtothe
ST90,youcantypetherequestedvalue.
6OpenthebuttonandselectApplytoallifyouwishtousethechosensettinginallthe
viewsinthecurrentpresentationmode.
Relatedtopics
Startingnormaloperation,page22
Adjustingthehorizontaldirectionofthesonarbeam
TheHorizontalviewintheST90presentationcoverstheentire360°omnidirectionalsector
Fortheotherviewsyoumustdenethehorizontaldirectionofthebeam.
Context
IntheHorizontalviewthecurrentbearingisshownwithacontinuouslinepointingout
fromthevesselposition.Theareacoveredbytheverticalbeamisshownasatrianglein
theHorizontalview.
Note
Thechoiceyoumakeisbydefaultonlyappliedtothecurrentlyselected(active)view.The
activeviewisidentiedwithathickerborder.
Anewtrackedobjectisautomaticallygivenprioritystatus.Thepriorityisidentiedwitha
"P".Thebearingandtiltsettingsareautomaticallyadjustedtofollowthemovementsofthe
trackedtarget.Thebearinglineisautomaticallylockedontheobjecttoreectsitsbearing.
Procedure
1Clickintheviewyouwanttoactivate.
Theactiveviewisidentiedwithathickerborder.UnlessyouusetheApplytoall
function,allchangesyoumakewillonlybeappliedtothisview.
Gettingstarted
