WhentheST90isnotused
WhenyoudonotusetheST90,turnofftheentiresystem.
Note
YoumustneverturnofftheST90bymeansoftheon/offswitchontheProcessorUnit.
YoumustALWAYSusetheOperatingPanel.
Whenyouaredockingyourvessel
YoumustneversettheST90tonormaloperationwhentheshipisindrydock.The
transducermaybedamagedifittransmitsinopenair.Topreventinadvertentuseofthe
ST90,pulloutthemainsplugontheProcessorUnitwheneveryourvesselisindrydock.
Additionalprecautionarymeasurersshouldbeconsidered.
Ifsomethingbreaksdown
Ifyoubelievethatsomethinghasbrokendown,contactyourlocaldealer.Alistofallour
dealersisprovidedonourwebsite.
•https://www.simrad.com
Ifyouareunabletocontactadealer,observethesupportinformationinthispublication.
WhenyouwanttoturnofftheST90
YoumustneverturnofftheST90bymeansoftheon/offswitchontheProcessorUnit.
WhenyoudonotusetheST90,turnitoffwiththePowerbuttonontheOperatingPanel.
IfthetransducerisloweredwhenyouturnofftheST90,itisautomaticallyretractedto
itsupperposition.
Note
IfyouturnofftheST90bymeansoftheon/offswitchontheProcessorUnityoumaydamage
thesoftwareandtheinterfacesettingsusedtocommunicatewithexternaldevices.
Manualoperationofthehullunit
Intheeventofimproperoperation,thepowerfulelectricmotoronthehullunitmaycause
seriousdamagetotheequipmentand/orinjurytopersonnel.Therefore,before
youstart
manualoperation,readcarefullythroughtherelevantoperatingprocedures.
Note
Youmustfamiliarizeyourselfwiththecorrecthandlingmethodsandtherelevantsafety
requirements.
SimradST90OperatorManual
