Simrad ST90 User Manual

457420/A
123
4Loweringthetransducer:
aSettheswitchtopositionLOWER.
LoweringisautomaticallystoppedwhentheLowerLimitSwitchisactivated.If
necessary,thetransducercanbestoppedinanypositionbysettingtheHoist/Lower
SwitchtoSTOP.
bSettheswitchtopositionSTOP.
5Hoistingthetransducer:
aSettheswitchtopositionHOIST.
HoistingisautomaticallystoppedwhentheUpperLimitSwitchisactivated.If
necessary,thetransducercanbestoppedinanypositionbysettingtheHoist/Lower
SwitchtoSTOP.
bSettheswitchtopositionSTOP.
6LocatetheHoist/LowerSwitch(S302).SettheswitchtopositionREMOTE.
Note
FornormaloperationfromtheOperatingPanel,theswitchmustbesettoREMOTE.
7Closethecabinetdoor.
Relatedtopics
Loweringandhoistingthetransducerfromthesonarroom,page121
Operatingprocedures
