Simrad ST90 User Manual

457420/A
125
bRemovethehandcrankfromitsstorageposition.
cRemovetheplasticplugonthetopcoverofthehullunit.
dMountthehandcrankontothestubshaftthroughtheholeinthetopcover.
eLocatethebrakereleasescrewonthemotor.
fUsean4mmAllenkeytorotatethescrewclockwiseuntilthemotorbrakeis
released.
gTurnthecrankuntilthetransducerisfullylowered.
7Hoistingthetransducer
aTurnthecrankuntilthetransducerisfullyretracted.
bLoosenthebrakereleasescrewtoengagethemotorbrake.
cCheckwiththehandcranktoensurethatthemotorbrakeisengaged.
dRemovethehandcrankfromthestubshaft,andmountitinitsstoragepositionin
theMotorControlUnit.
eActivatetheMotorProtectingSwitch(S301)bypressingtheoperatinghandletoON.
8MakesurethattheHoist/LowerSwitchissettoREMOTE.
Note
FornormaloperationfromtheOperatingPanel,theswitchmustbesettoREMOTE.
9Closethecabinetdoor.
10Insertthemainsfusesforthehullunit.
Relatedtopics
Loweringandhoistingthetransducerfromthesonarroom,page121
Operatingprocedures
